Caroma Urbane II Luxe Cleanflush Wall Faced Invisi Series II Toilet Suite

The Luxe version of the Urbane II wall-faced suite, on the Invisi Series II in-wall cistern so the plumbing stays hidden and the room keeps its lines. Cleanflush rimless technology means no lip inside the bowl and clear visibility of any build-up, with GermGard antimicrobial protection on both the pan and the seat. The profile is kept low and simple, and the seat closes softly.

• Cleanflush rimless bowl with no lip inside, giving a full clean and clear visibility of any grime
• GermGard antimicrobial protection added to both seat and pan
• Concealed cistern can go into a wall with a 90mm cavity, under a benchtop, or in a duct or ceiling, and stays accessible for service
• Space saving, with the cistern in the wall giving the illusion of a larger room
• Soft closing seat, so no slamming lids at night
• Patented Uni-Orbital connector extends the set-out to any position within a 50mm radius, which handles awkward plumbing
• Supported by a 20 year warranty

Specifications

WELS water efficiency: WELS 4 star ratedWELS water consumption: Dual flush, 4.5L/3L (3.5L average flush)WELS registration number: L06663Watermark certification: All Caroma toilet pans, cisterns and components are Watermark certifiedConstruction material: Vitreous China PanFinish/coating: Gloss white ceramic glazeOverall height: 470mm (pan & seat), 814 - 984mm to cistern top (in wall)Pan height: 440mm (excluding seat)Projection from wall: 570mmOverall width: 350mm (pan), 400mm cistern (in wall)Trap: Universal S or P trapSet out: S Trap 60 - 120mm, P Trap 185mmWater inlet location: N/AWarranty: 20 years

Find out more about WELS and Watermark certification and the important role they play in helping you choose water-efficient and safe products that are manufactured to strict Australian plumbing and building standards.

What's In The Box

PanCaroma Urbane Cleanflush pan in white, made from quality Vitreous China and featuring added height, making it easier to get on and off. Includes fixing kit and Uni-orbital connector, Caroma's patented waste trap connector for flexible installations, extends any position up to 50mm radius.

CisternCaroma Invisi Series II 4.5/3L behind the wall cistern. Suitable for inwall, induct, under-counter or induct/in-ceiling installations.

SeatCaroma Liano soft-close hinge seat in white, with a quick-release feature for ease of cleaning and slim lid for a low profile look.

Downloads

Download the specification sheet below:

Caroma Urbane II Luxe Cleanflush Wall Faced Invisi Series II Toilet Suite

Download the installation instructions below:

Caroma Urbane II Invisi Series II Cistern InstallCaroma Urbane II Invisi Series II Pan Install
